MRF89XAM8A

TABLE 4-1:

RECOMMENDED OPERATING CONDITIONS

Parameter

Ambient Operating Temperature

Supply Voltage for RF, Analog and Digital Circuits

Supply Voltage for Digital I/O

Input High Voltage (V IH )

Input Low Voltage (V IL )

Min

-40

2.1

2.1

0.5 * V IN

-0.3V

Typ

—

—

—

—

—

Max

+85

3.6

3.6

V IN + 0.3

0.2 * V IN

Unit

°C

V

V

V

V

Condition

—

—

—

—

—

AC Peak Voltage on Open Collector Outputs (IO) (1) V IN – 1.5

—

V IN + 1.5

V

—

Note 1:

At minimum, V IN – 1.5V should not be lower than 1.8V.

TABLE 4-2:

CURRENT CONSUMPTION

Symbol

I DDSL

Chip Mode

Sleep

Min

—

Typ

0.1

Max

2

Unit

μA

Condition

Sleep clock disabled, all blocks

disabled

I DDST

I DDFS

I DDTX

I DDRX

Idle

Frequency Synthesizer

Tx

Rx

—

—

—

—

—

65

1.3

25

16

3.0

80

1.7

30

21

3.5

μA

mA

mA

mA

mA

Oscillator and baseband enabled

Frequency synthesizer running

Output power = +10 dBm

Output power = +1 dBm (1)

—

Note 1:

Guaranteed by design and characterization.

TABLE 4-3:

DIGITAL I/O PIN INPUT SPECIFICATIONS (1)

Symbol

V IL

V IH

I IL

I IH

V OL

V OH

Characteristic

Input Low Voltage

Input High Voltage

Input Low Leakage Current (2)

Input High Leakage Current

Digital Low Output Voltage

Digital Low Output

Min

—

0.8 * V IN

-0.5

-0.5

—

0.9 * V IN

Typ

—

—

—

—

—

—

Max

0.2 * V IN

—

0.5

0.5

0.1 * V IN

—

Unit

V

V

μA

μA

—

V

Condition

—

—

V IL = 0V

V IH = V IN , V IN = 3.7

I OL = 1 mA

I OH = -1 mA

Note 1:

2:

Measurement Conditions: T A = 25°C, V IN = 3.3V, Crystal Frequency = 12.8 MHz, unless otherwise

specified.

Negative current is defined as the current sourced by the pin.

DS70651A-page 22

Preliminary

? 2010 Microchip Technology Inc.
